Cisco Nexus 9800 Fabric Modules

High-capacity fabric modules provide the internal switching fabric for Nexus 9800 Series chassis — connecting all line cards with N+1 redundancy for non-stop forwarding and hot-swappable field replacement.

Cisco Nexus 9800 Fabric Module
Fabric Module N+1 Redundancy Hot-Swappable High Capacity

Product Overview

Internal Switching Fabric

Fabric modules interconnect all line card slots within the chassis, providing the high-bandwidth internal switching path for data movement.

N+1 Redundancy

Extra fabric module provides full redundancy — if one module fails, the remaining modules maintain full line-rate throughput.

Hot-Swappable

Field-replaceable without powering down the chassis, maintaining full operations during fabric module maintenance.

High-Bandwidth Fabric

Each fabric module contributes bandwidth to the chassis backplane, enabling up to 115.2 Tbps aggregate switching capacity.

800G Future-Ready

Fabric architecture designed to support next-generation 800G line cards as they become available.

Two Variants

N9K-C9808-FM-A for the Nexus 9808 chassis and N9K-C9804-FM-A for the Nexus 9804 chassis — matched to each form factor.

Features and Benefits

The backbone of your Nexus 9800 chassis.

Fabric modules provide the high-bandwidth interconnect that enables the Nexus 9800 to deliver industry-leading throughput with full redundancy.

Non-Stop Forwarding

N+1 redundancy ensures full line-rate throughput is maintained even with a fabric module failure.

Zero-Downtime Maintenance

Hot-swappable design allows fabric module replacement without impacting chassis operations or data plane traffic.

Scalable Architecture

Fabric modules scale with the chassis to support the full throughput of all installed line cards.

Fabric Module Variants

Model
Description
N9K-C9808-FM-A
Fabric module for the Nexus 9808 (8-slot) chassis. 8 fabric module slots with N+1 redundancy.
N9K-C9804-FM-A
Fabric module for the Nexus 9804 (4-slot) chassis. Matched to the compact chassis form factor.

Specifications

N9K-C9808-FM-A

ChassisNexus 9808
Fabric module slots8
RedundancyN+1
ReplacementHot-swappable

N9K-C9804-FM-A

ChassisNexus 9804
RedundancyN+1
ReplacementHot-swappable

Documentation

Nexus 9800 Series Data Sheet

Full specifications for chassis, line cards, supervisors, and fabric modules.

Download PDF ›
