Extend your WAN across clouds and applications with a virtual routing platform—purpose-built for the cloud.
The Cisco® Catalyst® 8000V Edge Software (Catalyst 8000V) is a virtual-form-factor router that delivers comprehensive SD-WAN, WAN gateway, and network services functions into virtual and cloud environments. Using familiar, industry-leading Cisco IOS® XE Software networking capabilities, the Catalyst 8000V enables enterprises to transparently extend their WANs into provider-hosted clouds. Similarly, cloud providers themselves can use the Catalyst 8000V to offer enterprise-class networking services to their tenants or customers.
To save costs and become more agile, businesses small and large are increasingly virtualizing their data center infrastructures and applications. Many enterprises have started deploying IT applications in virtualized data centers that are built and managed by third-party service providers. These external data centers, known as provider-hosted clouds, allow enterprises to gain infrastructure and resources on demand and become even more operationally efficient.
However, the shared-infrastructure, shared-resource cloud environment poses networking and security problems for enterprises:
The cloud also presents networking challenges for cloud providers:
The Cisco Catalyst 8000V addresses these cloud-based networking and security constraints.
In addition to bringing enterprise-class networking services and security to public cloud environments, the Cisco Catalyst 8000V can be used as a building block for scalable network service offerings. The Network-Functions-Virtualization (NFV) components allow the Catalyst 8000V to fill roles traditionally reserved for hardware-based devices. Virtualizing these complex functions allows service providers to consolidate numerous instances onto a single server, and to easily scale as new customers come on board or networks are expanded.
Built on the same proven Cisco IOS XE Software platform for the Cisco Catalyst 8000 portfolio, it offers a rich set of features, including routing, VPN, firewall, Network Address Translation (NAT), QoS, application visibility, failover, and WAN optimization. Additional NFV uses such as virtual Route Reflector (vRR) is also supported by the Catalyst 8000V platform. This broad suite of functions empowers enterprises and cloud providers to build highly secure, optimized, scalable, and consistent hybrid networks.
Get agility, security, and visibility for a hybrid cloud world with Catalyst 8000V Edge Software.
Quickly and securely deploy a broad set of networking services with any cloud.
Apply and enforce centralized policies for all users.
Make migration to the cloud simple with a unified, programmable software image.
Optimize cloud applications and enhance user experience with advanced analytics.
The Cisco Catalyst 8000V is a software router that an enterprise or a cloud provider can deploy as a virtual machine in a provider-hosted cloud or in its own virtual environment. It can run on Cisco Unified Computing System™ (Cisco UCS®) servers as well as on servers from leading vendors that support VMware ESXi, Red Hat KVM virtualization, or on the Amazon EC2 cloud, Microsoft Azure cloud, or Google Cloud Platform. It contains Cisco IOS XE Software networking and security features.
A typical cloud provides IT infrastructure and resources to multiple customers or tenants. The Cisco Catalyst 8000V serves primarily as a router per tenant (Figure 1). That is, each tenant gets its own routing instance and hence, its own VPN connections, firewall policies, QoS rules, access control, and so on. The router can, however, also be deployed as a multitenant router, using Virtual Route Forwarding (VRF) to maintain separate routing tables and feature configurations for each tenant it services.

Figure: Cisco Catalyst 8000V positioned as a WAN gateway in a multitenant cloud
The Cisco Catalyst 8000V contains the same operating system—Cisco IOS XE Software—that runs inside the Catalyst 8000 product line. Providing control- and data-plane separation, multicore forwarding, and a modular architecture that allows for smooth insertion of networking features, Cisco IOS XE Software is well-suited for dynamic cloud environments. Cisco IOS XE Software is based on the stable, robust, and feature-rich Cisco IOS Software that has powered Cisco Integrated Services Routers (ISRs) and other hardware routers in demanding enterprise, service provider, and government networks for more than two decades.
Some key benefits of Cisco IOS XE Software include:
| Features | Description | |||
|---|---|---|---|---|
| Cisco IOS XE Software version | Cisco IOS XE Software (CSR Edition with selected Cisco IOS XE Software features) The software is available in ISO, BIN, OVA, and QCOW2 formats. |
|||
| Supported hypervisors |
|
|||
| Supported public clouds |
|
|||
| Supported I/O modes | The Catalyst 8000V supports several modes of communication between virtual Network Interface Cards (vNICs) and the physical hardware:
|
|||
| Virtual-machine specifications | The Catalyst 8000V can run on Cisco UCS servers as well as servers from vendors that support VMware ESXi, Red Hat KVM, or on the cloud: Amazon Web Services (AWS), Microsoft Azure, or Google Cloud Platform. The Catalyst 8000V requires the following from the virtualized server hardware:
|
|||
| Cisco IOS XE Software networking |
|
|||
| Cisco IOS XE Software security |
|
|||
| Management |
|
|||
Subscription licensing with support for Cisco Catalyst 8000V is offered using the three licenses of Cisco DNA Essentials, Cisco DNA Advantage, and Cisco DNA Premier.
Download the Cisco Catalyst 8000V Edge Software Data Sheet (PDF).
Pricing Notes:
